Editor’s Note: This post was originally published in 2013 and has been updated for comprehensiveness.
Tramp oils (hydraulic oil, lubricating oil and greases, and protective metal coatings) in coolant create expensive and frustrating problems. Tramp oils in coolant provide a breeding ground for bacteria and can cause problems ranging from unpleasant odor to employee skin rashes.
When tramp oils combine with other contaminants in coolant, they can form a sticky substance that clogs lines and sprays. When they hit the tool, the cooling effect of the coolant is reduced, causing shorter tool life, product staining, inaccurate tolerances and a smoky atmosphere in the plant.
Over the years, the need to keep coolants clean has become an even greater issue because:
- The cost of coolant replacement has increased.
- The cost of labor associated with coolant replacement has gone up.
- Tolerances have become more critical and rejects less acceptable.
- Employers and employees are more concerned about healthy working conditions and plant environment.
- Disposal of spent coolant has become expensive.
Discussions with machine tool manufacturers, coolant suppliers and plant personnel indicate that keeping tramp oil from seeping into coolant is virtually impossible. Since it cannot be prevented from entering the coolant, the only solution is to remove tramp oil continually. This has to be done whether the oil is generated by continuous small leaks from equipment (as is often the case) or whether the oil contamination is a one-time occurrence, such as a hydraulic line break.
Simple Modifications to Combat Tramp Oil
The most cost effective and simple method to combat tramp oil problem is a surface oil skimmer that mounts on the coolant reservoir and continually draws off surface oil.
Skimmers come in sizes and configurations to fit all applications, from small individual sumps to large holding tanks. The coolant reservoir also can be modified to increase tramp oil separation, thus further enhancing the value of the skimmer.
One such system modification reduces water turbulence in the coolant reservoir and creates a quiet area where tramp oils can separate. Extending a piece of sheet metal across the tank or reservoir so coolant can flow under, but not over, the sheet metal will serve as a baffle and create the quiet area needed for effective oil separation.
Another modification prevents the coolant from plunging into the reservoir. Plunging breaks tramp oil into smaller droplets and makes it more difficult for the oil to reach the surface. Adding a laminator plate or elbowing the inlet below the level of the liquid are two easy ways to reduce the plunging problem.
Where plunging and turbulence cannot be avoided, running the skimmer when machines are down has proved successful. By applying these simple modifications to oil skimmers, many companies have been able to extend, and in some cases, double the life of coolants and significantly reduce the other problems caused by tramp oils. In most cases, however, the coolant requires additional treatment, and here the role of the oil skimmer becomes even more important.
Use Oil Skimming to Enhance the Value of Your System
A plant engineer who has to decide which equipment he shall use to clean coolant faces many choices and decisions. Should he use a replaceable or permanent media type filter? Is a centrifuge or cyclone needed? Should he treat a portion of the flow or all of it?
The answers to these questions depend or the application and experts can guide the engineer through the options. Whatever system is selected, the oil skimmer will enhance the system's value because media replacement or cleaning is reduced.
Tramp oils can blind a filter, decreasing its life span and reducing its efficiency. A system typically has a "dirty" and a "clean" section. The oil skimmer mounts in the dirty section. On some systems where the unit is too small for the flow, there may be carryover that requires an oil skimmer on both sections.
Centrifuges operate more efficiently and require less cleaning if they are not exposed to slugs of free oil. In the presence of a lot of free oil, interfaces can shift and cause oil to exit with the coolant.
Solid and/or metal chips are removed from the coolant with magnetic separators and hydro-cyclones. Tramp oils should be removed before the metal chips to eliminate further emulsification and to help reduce oily build up in the system, which would require further maintenance and reduce efficiency.
How to Dispose of Spent Coolant
One reason to extend the life of coolant is the cost of its disposal; here again, the oil skimmer plays a significant part. There are two basic methods of coolant disposal:
- Break down the coolant, discharge the water and dispose of the concentrate.
- Haul away the entire coolant mixture.
Ultrafiltration and distillation are the most common ways to break down the coolant mixture. Each method works better if any oil in the mixture is first removed. When free oil is eliminated from the coolant, the distillation process requires less energy and ultrafiltration efficiency increases drastically.
Certain coolants can be discharged into municipal sanitary sewers if they are oil-free. Waste haulers typically charge more if the oil has not first been removed from the mixture. Some will not even take any mixture with oil. The solution to these problems is to skim the tramp oil first. In many cases, plants mix tramp oil with their fuel oil or sell it to waste oil processors.
Bonus: Increase the Usefulness of Your Oil Skimmer with a Decanter
When using oil skimmers to collect tramp oils, especially on a continuous basis, a decanter can increase the system's usefulness. Over time, even the small amounts of coolant removed with a skimmer can add up. Not only is coolant lost, but disposal of the tramp oil becomes more difficult and the frothy tramp oil that is removed contains coolant that will settle out in a quiet container. The decanting system returns coolant to the reservoir and channels the concentrated tramp oil to a collection tank.
Continuous removal of tramp oil extends the life of coolants. The use of oil skimmers to remove tramp oils is beneficial in every phase of coolant use, treatment, and disposal. Units are available for all size reservoirs and have demonstrated they can increase efficiency and reduce the loss of time and money.
